• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• PTFE Liner

Dimensions

Ball Width (in)	0.75 in
Head Diameter (in)	1.5 in
Ball Flat Diameter (in)	0.839 in
Thread Size	#5/8-18
Ball Diameter (in)	1.125 in
Base Diameter (in)	1 in
Housing Width (in)	0.562 in
Thread Length (in)	1.344 in
Length to Center of Ball (in)	2.5 in

Technical Specifications

Series	Precision
Product Selection Available SW	Y
Construction	Two-Piece Rod End
Liner	TEFLON* Fabric Liner
Housing Style	Female Rod End
Axial Load	546
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	8
Product Type	CFF
Configuration	Female
Zerk Fitting SW	N
Race Material	TEFLON
Lubrication Type	Self Lubricating
Across Wrench Flats	0.875
Lubrication	No Zerk Fitting
Thread	LH
Type	Female Rod End
Max Static Radial Load	5,460
Class	Precision
Bore Size (in)	0.6250 in
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	250 °F
Ability to Relubricate	None

General Specifications

UPC	662288721222
Weight	0.40 LB
Packaged Length	3.25 IN
Packaged Width	1.50 IN
Packaged Height	0.88 IN
HTC	8483.30.8055
Country of Origin	Mexico
