• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• Y Stud

Dimensions

Ball Diameter (in)	0.937 in
Base Diameter (in)	0.875 in
Ball Width (in)	0.625 in
Thread Size	#1/2-20
Head Diameter (in)	1.312 in
Thread Length (in)	1.031 in
Ball Flat Diameter (in)	0.698 in
Housing Width (in)	0.5 in
Stud Thread Length (in)	1 in
Stud Length to Hex (in)	1.13 in
Length to Center of Ball (in)	2.13 in
Stud Length to Center of Ball (in)	2 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Zerk Fitting SW	N
Configuration	Female
Axial Load	900
Bearing Type	Rod End
Lubrication Type	Grease
Product Type	CFF
Series	Commercial
Across Wrench Flats	0.75
Thread Type	UNF
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Selection Available SW	N
Y Stud Material	Carbon Steel - corrosion resistant plating
Construction	Two-Piece Rod End with Y Stud
Housing Style	Female Rod End
Type	Female Rod End
Lubrication	No Zerk Fitting
Max Static Radial Load	9,000
Misalignment Angle B3	24.3
Thread	RH
Class	Commercial
Bore Size (in)	0.5000 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724797
Weight	0.42 LB
Packaged Length	2.78 IN
Packaged Width	1.31 IN
Packaged Height	2.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
