• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• PTFE Liner

Dimensions

Base Diameter (in)	0.75 in
Thread Size	#7/16-20
Housing Width (in)	0.437 in
Ball Flat Diameter (in)	0.586 in
Thread Length (in)	0.906 in
Ball Diameter (in)	0.812 in
Ball Width (in)	0.562 in
Head Diameter (in)	1.125 in
Length to Center of Ball (in)	1.81 in

Technical Specifications

Race Material	TEFLON
Lubrication Type	Self Lubricating
Zerk Fitting SW	N
Axial Load	316
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Configuration	Female
Misalignment Angle - a Deg. +/-	7
Across Wrench Flats	0.625
Liner	TEFLON* Fabric Liner
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Precision
Construction	Two-Piece Rod End
Housing Style	Female Rod End
Bearing Type	Rod End
Thread Type	UNF
Product Type	CFF
Product Selection Available SW	Y
Type	Female Rod End
Lubrication	No Zerk Fitting
Thread	RH
Max Static Radial Load	3,160
Bore Size (in)	0.4375 in
Class	Precision
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	250 °F
Ability to Relubricate	None

General Specifications

UPC	662288721024
Weight	0.18 LB
Packaged Length	2.38 IN
Packaged Width	1.13 IN
Packaged Height	0.63 IN
HTC	8483.30.8055
Country of Origin	Mexico
