• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• PTFE Liner
• Y Stud

Dimensions

Thread Length (in)	0.781 in
Base Diameter (in)	0.688 in
Thread Size	#3/8-24
Housing Width (in)	0.406 in
Ball Flat Diameter (in)	0.517 in
Ball Width (in)	0.5 in
Head Diameter (in)	1 in
Ball Diameter (in)	0.718 in
Stud Thread Length (in)	0.8125 in
Stud Length to Hex (in)	0.91 in
Stud Length to Center of Ball (in)	1.54 in
Length to Center of Ball (in)	1.63 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Race Material	TEFLON
Product Type	CFF
Axial Load	295
Configuration	Female
Housing Style	Female Rod End
Thread Type	UNF
Series	Precision
Liner	TEFLON* Fabric Liner
Construction	Two-Piece Rod End with Stud
Zerk Fitting SW	N
Y Stud Material	Carbon Steel - corrosion resistant plating
Lubrication Type	Self Lubricating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Across Wrench Flats	0.562
Bearing Type	Rod End
Product Selection Available SW	N
Lubrication	No Zerk Fitting
Misalignment Angle B3	22.6
Thread	RH
Max Static Radial Load	2,950
Type	Female Rod End
Bore Size (in)	0.3750 in
Class	Precision
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	250 °F
Ability to Relubricate	None

General Specifications

UPC	662288721390
Weight	0.19 LB
Packaged Length	2.13 IN
Packaged Width	1.00 IN
Packaged Height	1.79 IN
HTC	8483.30.8055
Country of Origin	Mexico
