• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• Y Stud

Dimensions

Head Diameter (in)	0.875 in
Ball Width (in)	0.437 in
Base Diameter (in)	0.531 in
Housing Width (in)	0.344 in
Ball Diameter (in)	0.625 in
Thread Size	#5/16-24
Ball Flat Diameter (in)	0.447 in
Thread Length (in)	0.656 in
Stud Thread Length (in)	0.59375 in
Length to Center of Ball (in)	1.38 in
Stud Length to Center of Ball (in)	1.23 in
Stud Length to Hex (in)	0.69 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Zerk Fitting SW	N
Bearing Type	Rod End
Axial Load	380
Y Stud Material	Carbon Steel - corrosion resistant plating
Across Wrench Flats	0.437
Configuration	Female
Lubrication Type	Grease
Product Selection Available SW	N
Construction	Two-Piece Rod End with Y Stud
Outer Material	Carbon Steel - Corrosion Resistant Plating
Product Type	CFF
Series	Commercial
Housing Style	Female Rod End
Max Static Radial Load	3,800
Lubrication	No Zerk Fitting
Type	Female Rod End
Misalignment Angle B3	24.8
Thread	RH
Class	Commercial
Bore Size (in)	0.3125 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724674
Weight	0.11 LB
Packaged Length	1.81 IN
Packaged Width	0.88 IN
Packaged Height	1.45 IN
HTC	8483.30.8055
Country of Origin	Mexico
