• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• PTFE Liner

Dimensions

Housing Width (in)	0.344 in
Ball Flat Diameter (in)	0.447 in
Thread Size	#5/16-24
Base Diameter (in)	0.531 in
Ball Width (in)	0.437 in
Ball Diameter (in)	0.625 in
Thread Length (in)	0.656 in
Head Diameter (in)	0.875 in
Length to Center of Ball (in)	1.38 in

Technical Specifications

Construction	Two-Piece Rod End
Lubrication Type	Self Lubricating
Product Selection Available SW	Y
Axial Load	208
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Precision
Race Material	TEFLON
Product Type	CFF
Thread Type	UNF
Misalignment Angle - a Deg. +/-	7
Across Wrench Flats	0.437
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Zerk Fitting SW	N
Bearing Type	Rod End
Liner	TEFLON* Fabric Liner
Housing Style	Female Rod End
Configuration	Female
Type	Female Rod End
Lubrication	No Zerk Fitting
Thread	RH
Max Static Radial Load	2,080
Bore Size (in)	0.3125 in
Class	Precision
Lubrication Method	Self Lubricating
Ability to Relubricate	None
Maximum Ambient Temperature (F)	250 °F

General Specifications

UPC	662288721000
Weight	0.08 LB
Packaged Length	1.81 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
