• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads

Dimensions

Thread Length (in)	0.656 in
Housing Width (in)	0.344 in
Ball Flat Diameter (in)	0.447 in
Thread Size	#5/16-24
Ball Width (in)	0.437 in
Base Diameter (in)	0.531 in
Ball Diameter (in)	0.625 in
Head Diameter (in)	0.875 in
Length to Center of Ball (in)	1.38 in

Technical Specifications

Zerk Fitting SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Product Type	CFF
Series	Commercial
Construction	Two-Piece Rod End with Zerk Fitting
Across Wrench Flats	0.437
Thread Type	UNF
Configuration	Female
Product Selection Available SW	Y
Axial Load	380
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Grease
Housing Style	Female Rod End
Type	Female Rod End
Lubrication	Zerk Fitting
Max Static Radial Load	3,800
Thread	RH
Bore Size (in)	0.3125 in
Class	Commercial
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288724667
Weight	0.08 LB
Packaged Length	1.81 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
