• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads

Dimensions

Ball Diameter (in)	0.5 in
Thread Length (in)	0.656 in
Thread Size	#1/4-28
Ball Flat Diameter (in)	0.331 in
Base Diameter (in)	0.469 in
Ball Width (in)	0.375 in
Housing Width (in)	0.281 in
Head Diameter (in)	0.75 in
Length to Center of Ball (in)	1.31 in

Technical Specifications

Axial Load	320
Series	Commercial
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Configuration	Female
Product Type	CFF
Housing Style	Female Rod End
Across Wrench Flats	0.375
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Zerk Fitting SW	Y
Construction	Two-Piece Rod End with Zerk Fitting
Lubrication Type	Grease
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	8
Bearing Type	Rod End
Lubrication	Zerk Fitting
Thread	RH
Max Static Radial Load	3,200
Type	Female Rod End
Class	Commercial
Bore Size (in)	0.2500 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724629
Weight	0.07 LB
Packaged Length	1.69 IN
Packaged Width	0.75 IN
Packaged Height	0.38 IN
HTC	8483.30.8055
Country of Origin	Mexico
