• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads

Dimensions

Head Diameter (in)	0.625 in
Thread Size	#10-32
Thread Length (in)	0.469 in
Ball Flat Diameter (in)	0.306 in
Base Diameter (in)	0.375 in
Ball Width (in)	0.312 in
Housing Width (in)	0.25 in
Ball Diameter (in)	0.437 in
Length to Center of Ball (in)	1.06 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Lubrication Type	Grease
Housing Style	Female Rod End
Product Selection Available SW	Y
Zerk Fitting SW	N
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Axial Load	200
Series	Commercial
Misalignment Angle - a Deg. +/-	6.5
Thread Type	UNF
Construction	Two-Piece Rod End
Product Type	CFF
Bearing Type	Rod End
Across Wrench Flats	0.312
Configuration	Female
Lubrication	No Zerk Fitting
Type	Female Rod End
Thread	RH
Max Static Radial Load	2,000
Class	Commercial
Bore Size (in)	0.1875 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724599
Weight	0.04 LB
Packaged Length	1.38 IN
Packaged Width	0.63 IN
Packaged Height	0.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
