• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• PTFE Liner

Dimensions

Base Diameter (in)	1.125 in
Thread Size	#3/4-16
Ball Diameter (in)	1.312 in
Ball Width (in)	0.875 in
Housing Width (in)	0.687 in
Head Diameter (in)	1.75 in
Thread Length (in)	1.531 in
Ball Flat Diameter (in)	0.978 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Precision
Bearing Type	Rod End
Lubrication Type	Self Lubricating
Liner	TEFLON* Fabric Liner
Product Selection Available SW	Y
Housing Style	Female Rod End
Race Material	TEFLON
Thread Type	UNF
Misalignment Angle - a Deg. +/-	7
Zerk Fitting SW	N
Configuration	Female
Across Wrench Flats	1
Construction	Two-Piece Rod End
Product Type	CFF
Axial Load	830
Max Static Radial Load	8,300
Lubrication	No Zerk Fitting
Type	Female Rod End
Thread	RH
Bore Size (in)	0.7500 in
Class	Precision
Lubrication Method	Self Lubricating
Maximum Ambient Temperature (F)	250 °F
Ability to Relubricate	None

General Specifications

UPC	662288721055
Weight	0.59 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
