• Sealmaster® Bev Dry™ cast iron housing with bolt on end cap and back side shield for optimal protection
• Skwezloc® concentric locking for near perfect concentricity
• High performance triple contact seal design provide multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain relubrication
• Tapered land outer ring ensures that lubricant will be easily directed back to the raceway
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.

Dimensions

Bolt Size (in)	9/16 in
Overall Width (in)	4.38 in
Overall Length (in)	7.06 in
Overall Height (in)	2.107 in
Bore Diameter (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.938 in
Bolt Spacing (in)	5.8440 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Backside Shield/Seal	Backside Shield included loose in box
Outer Ring Land Profile	Tapered Lands
Options	Reduced Maintenance - Lubed for Life
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.94 in
Ability to Relubricate	No
Static Load Rating (lb)	5,139 lb
Max Operating Temperature (C)	104 °C
End Cap Available	No
Dynamic Load Rating (lb)	7,901 lb
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Max Operating Temperature (F)	220 °F
Maximum Speed (RPM)	1600 rpm
Bearing Insert Finish	Black Oxide
Housing Coating	Powder Coated
Size Code	2-111
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	2.297 in
Grease Fitting Thread Size	1/4-28
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Concentric
Insert	2-111TH RM
Bearing Type	Standard Duty
Housing Material	Cast Iron
Radial Clearance	Standard

General Specifications

UPC	662461373132
Weight	5.10 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
