• Sealmaster® Bev Dry™ cast iron housing with bolt on end cap and back side shield for optimal protection
• Skwezloc® concentric locking for near perfect concentricity
• High performance triple contact seal design provide multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain relubrication
• Tapered land outer ring ensures that lubricant will be easily directed back to the raceway
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	3.25 in
Overall Length (in)	5.56 in
Overall Height (in)	1.62 in
Bore Diameter (in)	1.25 in
Overall Height to End Cap (in)	1.87 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.56 in
Bolt Spacing (in)	4.594 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Backside Shield/Seal	Backside Shield included loose in box
Options	Reduced Maintenance - Lubed for Life
Housing Color	Black
Outer Ring Land Profile	Tapered Lands
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Setscrew Torque (in-lbs)	70 in/lbs
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.19 in
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	1.587 in
Vibration Frequency Outer Ring Defect	0.0595 cps
Static Load Rating (lb)	2,567 lb
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Vibration Frequency Fundamental Train	0.0066 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Concentric
Bearing Type	Standard Duty
Radial Clearance	Standard
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
End Cap Available	Yes
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	2300 rpm
Bearing Insert Material	52100 Bearing Steel
Insert	1-14TH RM
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	4,381 lb
Vibration Frequency Roller Spin	0.0385 cps
Size Code	2-13

General Specifications

UPC	662461369104
Weight	2.45 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
