• Sealmaster® Bev Dry™ cast iron housing with bolt on end cap and back side shield for optimal protection
• Skwezloc® concentric locking for near perfect concentricity
• High performance triple contact seal design provide multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain relubrication
• Tapered land outer ring ensures that lubricant will be easily directed back to the raceway
• Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	5/8 in
Overall Length (in)	6.38 in
Overall Height (in)	2.37 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.33 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Backside Shield/Seal	Backside Shield included loose in box
Misalignment Type	Static Only
Outer Ring Land Profile	Tapered Lands
Options	Reduced Maintenance - Lubed for Life
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	No
Locking Collar Outside Diameter (in)	3.6 in
Inner Race Heat Treat Method	Zone-Hardened
Static Load Rating (lb)	6,601 lb
Grease Fitting Thread Size	1/8 NPT
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Backside Inner Diameter	4.25
Radial Clearance	Standard
Size Code	2-23
Maximum Speed (RPM)	1350 rpm
Lube Fitting Type	HOUSING PLUGGED
Insert	2-2TH RM
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	9,752 lb
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric
Bearing Insert Finish	Black Oxide
Max Operating Temperature (F)	220 °F
End Cap Available	No
Housing Material	Cast Iron
Housing Coating	Powder Coated
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	2.723 in

General Specifications

UPC	662461375365
Weight	11.00 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
