• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	0.719 in
Base Diameter (in)	0.531 in
Head Diameter (in)	0.875 in
Ball Diameter (in)	0.625 in
Ball Width (in)	0.437 in
Housing Width (in)	0.344 in
Ball Flat Diameter (in)	0.447 in
Thread Size	#5/16-24
Length to Center of Ball (in)	1.38 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Configuration	Female
Misalignment Angle - a Deg. +/-	7
Thread Type	UNF
Construction	Three-Piece Rod End with Zerk Fitting
Zerk Fitting SW	Y
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Axial Load	750
Bearing Type	Rod End
Lubrication Type	Grease
Across Wrench Flats	0.437
Product Type	AR
Race Material	Carbon Steel - corrosion resistant plating
Housing Style	Female Rod End
Series	Precision Extra Capacity
Product Selection Available SW	Y
Thread	LH
Type	Female Rod End
Max Static Radial Load	7,500
Lubrication	Zerk Fitting
Class	Precision
Bore Size (in)	0.3125 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288720010
Weight	0.09 LB
Packaged Length	1.81 IN
Packaged Width	0.88 IN
Packaged Height	0.44 IN
HTC	8483.30.8055
Country of Origin	Mexico
