• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Diameter (in)	1.312 in
Housing Width (in)	0.687 in
Ball Width (in)	0.875 in
Thread Size	#3/4-16
Ball Flat Diameter (in)	0.978 in
Head Diameter (in)	1.75 in
Base Diameter (in)	1.125 in
Thread Length (in)	1.719 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Thread Type	UNF
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	7
Axial Load	2,320
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision Extra Capacity
Lubrication Type	Grease
Housing Style	Female Rod End
Construction	Three-Piece Rod End with Zerk Fitting
Race Material	Carbon Steel - corrosion resistant plating
Across Wrench Flats	1
Product Selection Available SW	Y
Zerk Fitting SW	Y
Configuration	Female
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Product Type	AR
Lubrication	Zerk Fitting
Max Static Radial Load	23,200
Thread	LH
Type	Female Rod End
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288720065
Weight	0.68 LB
Packaged Length	2.90 IN
Packaged Width	4.00 IN
Packaged Height	1.15 IN
HTC	8483.30.8055
Country of Origin	Mexico
