• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	1.469 in
Thread Size	#5/8-18
Ball Diameter (in)	0.937 in
Ball Width (in)	0.625 in
Head Diameter (in)	1.312 in
Ball Flat Diameter (in)	0.698 in
Housing Width (in)	0.5 in
Length to Center of Ball (in)	2.44 in

Technical Specifications

Configuration	Male
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Race Material	Carbon Steel - corrosion resistant plating
Product Type	ARE-20
Bearing Type	Rod End
Axial Load	1,350
Construction	Three-Piece Rod End with Zerk Fitting
Series	Precision Extra Capacity
Housing Style	Male Rod End
Misalignment Angle - a Deg. +/-	6
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Zerk Fitting SW	Y
Product Selection Available SW	Y
Lubrication Type	Grease
Type	Male Rod End
Thread	LH
Lubrication	Zerk Fitting
Max Static Radial Load	13,500
Bore Size (in)	0.5000 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288723417
Weight	0.31 LB
Packaged Length	3.09 IN
Packaged Width	1.31 IN
Packaged Height	0.63 IN
HTC	8483.30.8055
Country of Origin	Mexico
