• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Head Diameter (in)	1.75 in
Ball Flat Diameter (in)	0.978 in
Ball Diameter (in)	1.312 in
Thread Length (in)	1.719 in
Housing Width (in)	0.687 in
Ball Width (in)	0.875 in
Thread Size	#7/8-14
Length to Center of Ball (in)	2.88 in

Technical Specifications

Axial Load	2,320
Bearing Type	Rod End
Series	Precision Extra Capacity
Housing Style	Male Rod End
Product Type	ARE-20
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Selection Available SW	Y
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Race Material	Carbon Steel - corrosion resistant plating
Thread Type	UNF
Construction	Three-Piece Rod End with Zerk Fitting
Configuration	Male
Zerk Fitting SW	Y
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Grease
Thread	LH
Lubrication	Zerk Fitting
Max Static Radial Load	23,200
Type	Male Rod End
Bore Size (in)	0.7500 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288720201
Weight	0.66 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	3.75 IN
HTC	8483.30.8055
Country of Origin	Mexico
