• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	1.219 in
Ball Diameter (in)	0.718 in
Ball Width (in)	0.5 in
Housing Width (in)	0.406 in
Head Diameter (in)	1 in
Thread Size	#3/8-24
Ball Flat Diameter (in)	0.517 in
Length to Center of Ball (in)	1.94 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Product Type	ARE
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Zerk Fitting SW	Y
Housing Style	Male Rod End
Axial Load	958
Configuration	Male
Series	Precision Extra Capacity
Bearing Type	Rod End
Race Material	Carbon Steel - corrosion resistant plating
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Product Selection Available SW	Y
Lubrication Type	Grease
Misalignment Angle - a Deg. +/-	6
Thread Type	UNF
Thread	RH
Max Static Radial Load	9,580
Lubrication	Zerk Fitting
Type	Male Rod End
Bore Size (in)	0.3750 in
Class	Precision
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288719731
Weight	0.13 LB
Packaged Length	2.35 IN
Packaged Width	2.55 IN
Packaged Height	0.55 IN
HTC	8483.30.8055
Country of Origin	Mexico
