• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Housing Width (in)	0.281 in
Ball Flat Diameter (in)	0.331 in
Head Diameter (in)	0.75 in
Ball Width (in)	0.375 in
Thread Size	#1/4-28
Ball Diameter (in)	0.5 in
Thread Length (in)	0.969 in
Length to Center of Ball (in)	1.56 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Zerk Fitting SW	Y
Misalignment Angle - a Deg. +/-	8
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Product Selection Available SW	Y
Race Material	Carbon Steel - corrosion resistant plating
Lubrication Type	Grease
Bearing Type	Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision Extra Capacity
Product Type	ARE
Configuration	Male
Axial Load	448
Thread Type	UNF
Housing Style	Male Rod End
Max Static Radial Load	4,480
Thread	RH
Type	Male Rod End
Lubrication	Zerk Fitting
Bore Size (in)	0.2500 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719717
Weight	0.05 LB
Packaged Length	4.35 IN
Packaged Width	3.65 IN
Packaged Height	0.65 IN
HTC	8483.30.8055
Country of Origin	Mexico
