• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Size	#3/4-16
Ball Diameter (in)	1.312 in
Thread Length (in)	1.719 in
Head Diameter (in)	1.75 in
Ball Width (in)	0.875 in
Ball Flat Diameter (in)	0.978 in
Housing Width (in)	0.687 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Race Material	Carbon Steel - corrosion resistant plating
Bearing Type	Rod End
Axial Load	2,320
Misalignment Angle - a Deg. +/-	7
Thread Type	UNF
Lubrication Type	Grease
Housing Style	Male Rod End
Configuration	Male
Series	Precision Extra Capacity
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Type	ARE
Zerk Fitting SW	N
Construction	Three-Piece Rod End
Product Selection Available SW	Y
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Thread	RH
Lubrication	No Zerk Fitting
Type	Male Rod End
Max Static Radial Load	23,200
Bore Size (in)	0.7500 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288718994
Weight	0.63 LB
Packaged Length	2.10 IN
Packaged Width	5.10 IN
Packaged Height	0.95 IN
HTC	8483.30.8055
Country of Origin	Mexico
