• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Size	#5/8-18
Ball Width (in)	0.75 in
Head Diameter (in)	1.5 in
Ball Diameter (in)	1.125 in
Ball Flat Diameter (in)	0.839 in
Thread Length (in)	1.594 in
Housing Width (in)	0.562 in
Length to Center of Ball (in)	2.63 in

Technical Specifications

Lubrication Type	Grease
Axial Load	1,730
Thread Type	UNF
Product Type	ARE
Housing Style	Male Rod End
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	8
Race Material	Carbon Steel - corrosion resistant plating
Series	Precision Extra Capacity
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Construction	Three-Piece Rod End with Zerk Fitting
Zerk Fitting SW	Y
Configuration	Male
Bearing Type	Rod End
Lubrication	Zerk Fitting
Max Static Radial Load	17,300
Type	Male Rod End
Thread	RH
Class	Precision
Bore Size (in)	0.6250 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288719755
Weight	0.41 LB
Packaged Length	2.65 IN
Packaged Width	3.60 IN
Packaged Height	0.85 IN
HTC	8483.30.8055
Country of Origin	Mexico
