• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Base Diameter (in)	0.688 in
Ball Diameter (in)	0.718 in
Thread Size	#3/8-24
Thread Length (in)	0.906 in
Ball Width (in)	0.5 in
Housing Width (in)	0.406 in
Head Diameter (in)	1 in
Ball Flat Diameter (in)	0.517 in
Length to Center of Ball (in)	1.63 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision Extra Capacity
Across Wrench Flats	0.562
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Axial Load	957
Lubrication Type	Grease
Thread Type	UNF
Product Type	AR
Construction	Three-Piece Rod End with Zerk Fitting
Housing Style	Female Rod End
Misalignment Angle - a Deg. +/-	6
Product Selection Available SW	Y
Race Material	Carbon Steel - corrosion resistant plating
Bearing Type	Rod End
Configuration	Female
Zerk Fitting SW	Y
Thread	RH
Max Static Radial Load	9,570
Lubrication	Zerk Fitting
Type	Female Rod End
Class	Precision
Bore Size (in)	0.3750 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719663
Weight	0.16 LB
Packaged Length	3.70 IN
Packaged Width	3.50 IN
Packaged Height	2.20 IN
HTC	8483.30.8055
Country of Origin	Mexico
