• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Diameter (in)	0.625 in
Ball Width (in)	0.437 in
Head Diameter (in)	0.875 in
Base Diameter (in)	0.531 in
Thread Length (in)	0.719 in
Ball Flat Diameter (in)	0.447 in
Thread Size	#5/16-24
Housing Width (in)	0.344 in
Length to Center of Ball (in)	1.38 in

Technical Specifications

Zerk Fitting SW	Y
Configuration	Female
Axial Load	750
Lubrication Type	Grease
Product Type	AR
Across Wrench Flats	0.437
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision Extra Capacity
Thread Type	UNF
Bearing Type	Rod End
Product Selection Available SW	Y
Housing Style	Female Rod End
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Misalignment Angle - a Deg. +/-	7
Construction	Three-Piece Rod End with Zerk Fitting
Race Material	Carbon Steel - corrosion resistant plating
Thread	RH
Type	Female Rod End
Max Static Radial Load	7,500
Lubrication	Zerk Fitting
Bore Size (in)	0.3125 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719656
Weight	0.05 LB
Packaged Length	2.60 IN
Packaged Width	2.10 IN
Packaged Height	0.55 IN
HTC	8483.30.8055
Country of Origin	Mexico
