• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	0.719 in
Base Diameter (in)	0.531 in
Housing Width (in)	0.344 in
Ball Diameter (in)	0.625 in
Ball Width (in)	0.437 in
Thread Size	#5/16-24
Head Diameter (in)	0.875 in
Ball Flat Diameter (in)	0.447 in
Length to Center of Ball (in)	1.38 in

Technical Specifications

Zerk Fitting SW	N
Thread Type	UNF
Bearing Type	Rod End
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	7
Configuration	Female
Product Type	AR
Axial Load	750
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision Extra Capacity
Housing Style	Female Rod End
Race Material	Carbon Steel - corrosion resistant plating
Lubrication Type	Grease
Across Wrench Flats	0.437
Construction	Three-Piece Rod End
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Thread	RH
Lubrication	No Zerk Fitting
Type	Female Rod End
Max Static Radial Load	7,500
Class	Precision
Bore Size (in)	0.3125 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288718871
Weight	0.05 LB
Packaged Length	1.75 IN
Packaged Width	3.05 IN
Packaged Height	0.70 IN
HTC	8483.30.8055
Country of Origin	Mexico
