• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Flat Diameter (in)	0.331 in
Head Diameter (in)	0.75 in
Base Diameter (in)	0.469 in
Ball Diameter (in)	0.5 in
Housing Width (in)	0.281 in
Thread Size	#1/4-28
Ball Width (in)	0.375 in
Thread Length (in)	0.719 in
Length to Center of Ball (in)	1.31 in

Technical Specifications

Race Material	Carbon Steel - corrosion resistant plating
Product Type	AR
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Across Wrench Flats	0.375
Configuration	Female
Series	Precision Extra Capacity
Zerk Fitting SW	N
Axial Load	537
Housing Style	Female Rod End
Product Selection Available SW	Y
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	8
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Thread Type	UNF
Lubrication Type	Grease
Construction	Three-Piece Rod End
Lubrication	No Zerk Fitting
Thread	RH
Type	Female Rod End
Max Static Radial Load	5,370
Class	Precision
Bore Size (in)	0.2500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288718864
Weight	0.05 LB
Packaged Length	2.10 IN
Packaged Width	4.15 IN
Packaged Height	0.70 IN
HTC	8483.30.8055
Country of Origin	Mexico
