• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Head Diameter (in)	1.75 in
Housing Width (in)	0.687 in
Thread Size	#3/4-16
Thread Length (in)	1.719 in
Ball Width (in)	0.875 in
Ball Diameter (in)	1.312 in
Base Diameter (in)	1.125 in
Ball Flat Diameter (in)	0.978 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Product Selection Available SW	Y
Housing Style	Female Rod End
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Grease
Thread Type	UNF
Across Wrench Flats	1
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Zerk Fitting SW	N
Bearing Type	Rod End
Product Type	AR
Construction	Three-Piece Rod End
Configuration	Female
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Axial Load	2,320
Series	Precision Extra Capacity
Race Material	Carbon Steel - corrosion resistant plating
Max Static Radial Load	23,200
Lubrication	No Zerk Fitting
Thread	RH
Type	Female Rod End
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288718925
Weight	0.66 LB
Packaged Length	3.75 IN
Packaged Width	1.75 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
