• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Housing Width (in)	0.562 in
Ball Flat Diameter (in)	0.839 in
Head Diameter (in)	1.5 in
Thread Length (in)	1.469 in
Ball Diameter (in)	1.125 in
Thread Size	#5/8-18
Base Diameter (in)	1 in
Ball Width (in)	0.75 in
Length to Center of Ball (in)	2.5 in

Technical Specifications

Bearing Type	Rod End
Housing Style	Female Rod End
Product Selection Available SW	Y
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	4130 Alloy Steel - Heat Treated - Corrosion Resistant Plating
Zerk Fitting SW	Y
Axial Load	1,730
Construction	Three-Piece Rod End with Zerk Fitting
Lubrication Type	Grease
Across Wrench Flats	0.875
Race Material	Carbon Steel - corrosion resistant plating
Misalignment Angle - a Deg. +/-	8
Series	Precision Extra Capacity
Thread Type	UNF
Product Type	AR
Configuration	Female
Thread	RH
Type	Female Rod End
Max Static Radial Load	17,300
Lubrication	Zerk Fitting
Class	Precision
Bore Size (in)	0.6250 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719694
Weight	0.45 LB
Packaged Length	2.88 IN
Packaged Width	0.88 IN
Packaged Height	3.25 IN
HTC	8483.30.8055
Country of Origin	Mexico
