• Standard Bearings: Commercially available Tapered Roller Bearings provide maximum overhung load capacity.
• Standard Seals: Commercially available double lip seals ride on plunge ground shafts, with exclusive barrier seal arrangement.
• Options and Accessories: Complete range of motor mounts, belt guards, backstops, trough ends and screw conveyor sealing options.

Technical Specifications

Screw Diameter	18-24
Product Type	TorqTaper Plus (SMTP)
Key	.500 x .500 x 3.75
Used Ratio	5:1, 9:1, 15:1, 25:1 or 35:1
Drive Shaft Diameter	3.4375 in
Reducer Size	215
Series	215DSP
Distance between Shaft holes (in)	4 in
Hole Diameter (in)	0.9063 in
Housing Material	Steel
Shaft Projecting Length (in)	13.14 in
Accessory Type	Screw Conveyor Accessories

General Specifications

UPC	662460492827
Weight	67.80 LB
Packaged Length	3.50 IN
Packaged Width	27.50 IN
Packaged Height	3.50 IN
HTC	8483.90.5090
Country of Origin	United States of America
