• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Machine Polished 316 stainless steel housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore SSHERA gear drives.

Technical Specifications

Service Factor	1
Housing Material	Stainless Steel
Product Type	RIGHT ANGLE
Length Through Bore (in)	8 in
Housing Height (in)	9.61 in
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Housing Length (in)	10.52 in
Series Code	HERA55
Nominal Ratio	7.5:1
Ratio	7.94:1
Output Shaft	Hollow Bore
Output Diameter (in)	1.250 in
Certifications	IP69K, USDA Accepted Equipment
Input Style	Shaft
Product Line	HERA
Mounting Type	AS
Input HP @ 1750 RPM	13
Reduction	Double
Center Distance (in)	3.675 in
Style	AS
Output RPM	220.4
Input HP	13
Input Diameter (in)	1.248 in
Housing Dimensions (in)	(L)10.52 x (H)9.61 x (W)8.0 in
Output Torque Rating (in-lb)	3346 in/lbs
Gear Drive SIze	SSHERA55
Housing Width (in)	8 in
