• Standard Bearings: Commercially available Tapered Roller Bearings provide maximum overhung load capacity.
• Standard Seals: Commercially available double lip seals ride on plunge ground shafts, with exclusive barrier seal arrangement.
• Options and Accessories: Complete range of motor mounts, belt guards, backstops, trough ends and screw conveyor sealing options.

Technical Specifications

Key	.250 x .250 x 2.75
Screw Diameter	9-12
Product Type	TorqTaper Plus (SMTP)
Reducer Size	115
Drive Shaft Diameter	2 in
Used Ratio	5:1, 9:1, 15:1, 25:1 or 35:1
Series	115DSP
Hole Diameter (in)	0.6563 in
Distance between Shaft holes (in)	3 in
Housing Material	Steel
Shaft Projecting Length (in)	6 in
Accessory Type	Screw Conveyor Accessories

General Specifications

UPC	662460492209
Weight	19.76 LB
Packaged Length	16.30 IN
Packaged Width	7.50 IN
Packaged Height	5.60 IN
HTC	8483.90.5090
Country of Origin	United States of America
