• Standard Bearings: Commercially available Tapered Roller Bearings provide maximum overhung load capacity.
• Standard Seals: Commercially available double lip seals ride on plunge ground shafts, with exclusive barrier seal arrangement.
• Options and Accessories: Complete range of motor mounts, belt guards, backstops, trough ends and screw conveyor sealing options.

Technical Specifications

Key	.188 x .188 x 2.88
Screw Diameter	12,14
Product Type	TorqTaper Plus (SMTP)
Used Ratio	5:1, 9:1, 15:1, 25:1 or 35:1
Drive Shaft Diameter	2.4375 in
Reducer Size	107
Distance between Shaft holes (in)	3 in
Hole Diameter (in)	0.6563 in
Series	107DSP
Housing Material	Steel
Shaft Projecting Length (in)	6.69 in
Accessory Type	Screw Conveyor Accessories

General Specifications

UPC	662460492018
Weight	15.97 LB
Packaged Length	19.10 IN
Packaged Width	3.80 IN
Packaged Height	3.40 IN
HTC	8483.90.5090
Country of Origin	United States of America
