• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Material	Steel
Bushing Used	Split Taper
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Pitch Diameter (in)	4.81 in
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.5 in
Number of Teeth	15
Max Bore (in)	1.75 in
Chain Pitch (in)	1 in
Overall Length (in)	2.140625 in
Outside Diameter (in)	5.305 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Tooth Width (in)	0.575 in
Hub Diameter (in)	3 in
Length Through Bore (in)	1.938 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Pitch Type	Single
Hardened Teeth	Yes
Hub Projection (in)	1.375 in
Number of Hubs	1
Overall Width (in)	2.104625 in

General Specifications

UPC	662289136117
Weight	3.14 LB
Packaged Length	5.80 IN
Packaged Width	5.50 IN
Packaged Height	1.60 IN
HTC	8483.90.1050
Country of Origin	China
