• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	1.75 in
Min Bore (in)	0.5 in
Pitch Diameter (in)	3.844 in
Number of Teeth	16
Chain Pitch (in)	0.75 in
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Material	Steel, Hardened Teeth
Outside Diameter (in)	4.221 in
Overall Length (in)	2.165725 in
Bore Type	Bushed Bore
Number of Strands/Width	2
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Pitch Type	Single

General Specifications

UPC	662289279302
Weight	2.42 LB
Packaged Length	4.70 IN
Packaged Width	4.90 IN
Packaged Height	1.50 IN
HTC	8483.90.1050
Country of Origin	China
