• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	1.5 in
Product Type	Bushed Roller Chain Sprocket
Chain Pitch (in)	1 in
Bushing Used	Split Taper
Number of Teeth	10
Material	Steel, Hardened Teeth
Min Bore (in)	0.375 in
Pitch Diameter (in)	3.236 in
Chain Used	No. 80, 1 in. Pitch ANSI Chain
Overall Length (in)	2.1003 in
Bore Type	Bushed Bore
Outside Diameter (in)	3.678 in
Number of Strands/Width	1
Hub Diameter (in)	2.494 in
Maximum Bore (in)	1.5 in
Maximum Bore (mm)	38 mm
Minimum Bore (mm)	10 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289723065
Weight	1.53 LB
Packaged Length	4.20 IN
Packaged Width	4.00 IN
Packaged Height	1.70 IN
HTC	8483.90.1050
Country of Origin	China
