• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Chain Pitch (in)	0.75 in
Product Type	Finished Bore Roller Chain Sprocket
Number of Teeth	15
Pitch Diameter (in)	3.607 in
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Material	Steel, Hardened Teeth
Outside Diameter (in)	3.978 in
Hub Projection (in)	0.796875 in
Length Through Bore (in)	1.25 in
Tooth Width (in)	0.459 in
Bore Type	Finished Bore
Sprocket Material	Steel, Hardened Teeth
Hub Diameter (in)	2.875 in
Hub Type	Type B
Overall Length (in)	1.25 in
Number of Strands/Width	1
Bore Diameter (in)	0.875 in
Pitch Type	Single
Hardened Teeth	With Hardened Teeth
Keyway Size	3/16 X 3/32
Minimum Bore (mm)	0 mm
Maximum Bore (in)	0.88 in
Maximum Bore (mm)	0 mm

General Specifications

UPC	662289985616
Weight	2.29 LB
Packaged Length	4.00 IN
Packaged Width	4.00 IN
Packaged Height	1.40 IN
HTC	8483.90.1050
Country of Origin	United States of America
