• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Product Type	Finished Bore Roller Chain Sprocket
Material	Steel, Hardened Teeth
Chain Pitch (in)	0.75 in
Number of Teeth	13
Chain Used	No. 60, 3/4 in. Pitch ANSI Chain
Pitch Diameter (in)	3.134 in
Length Through Bore (in)	1.25 in
Tooth Width (in)	0.459 in
Outside Diameter (in)	3.493 in
Bore Type	Finished Bore
Hub Projection (in)	0.796875 in
Hub Type	Type B
Sprocket Material	Steel, Hardened Teeth
Hub Diameter (in)	2.34375 in
Overall Length (in)	1.25 in
Number of Strands/Width	1
Bore Diameter (in)	1.375 in
Hardened Teeth	With Hardened Teeth
Keyway Size	5/16 x 5/32
Pitch Type	Single
Maximum Bore (in)	1.38 in
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm

General Specifications

UPC	662289985494
Weight	1.32 LB
Packaged Length	3.56 IN
Packaged Width	3.56 IN
Packaged Height	1.44 IN
HTC	8483.90.1050
Country of Origin	United States of America
