• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Max Bore (in)	1.75 in
Bushing Used	Split Taper
Number of Teeth	29
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Material	Steel, Hardened Teeth
Chain Pitch (in)	0.625 in
Pitch Diameter (in)	5.781 in
Outside Diameter (in)	6.122 in
Overall Length (in)	2.221225 in
Hub Diameter (in)	3 in
Sprocket Material	Steel, Hardened Teeth
Bore Type	Bushed Bore
Hub Type	Bushed
Tooth Width (in)	0.343 in
Length Through Bore (in)	2.9375 in
Number of Strands/Width	1
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Number of Hubs	1
Pitch Type	Single
Max Bushing Bore (in)	1.75 in
Min Bushing Bore (in)	0.5 in

General Specifications

UPC	662289105403
Weight	3.32 LB
Packaged Length	6.56 IN
Packaged Width	6.56 IN
Packaged Height	1.31 IN
HTC	8483.90.1050
Country of Origin	China
