• This Product has the Browning Exclusive Twice the Life Guarantee
• Compact design
• Taper bore bushings are available in popular inch bore sizes
• Hardened Teeth at No Extra Cost - Drives sizes up to 30 teeth on 40 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Chain Pitch (in)	0.625 in
Bushing Used	Split Taper
Max Bore (in)	1.75 in
Number of Teeth	26
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	5.185 in
Material	Steel, Hardened Teeth
Overall Length (in)	2.221225 in
Outside Diameter (in)	5.522 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289205325
Weight	2.85 LB
Packaged Length	6.40 IN
Packaged Width	6.10 IN
Packaged Height	1.50 IN
HTC	8483.90.1050
Country of Origin	China
