• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Pitch (in)	0.625 in
Number of Teeth	11
Material	Steel
Pitch Diameter (in)	2.218 in
Max Bore (in)	1 in
Bushing Used	Split Taper
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.375 in
Overall Length (in)	1.60625 in
Outside Diameter (in)	2.504 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Length Through Bore (in)	1 in
Tooth Width (in)	0.343 in
Hub Diameter (in)	2.015 in
Maximum Bore (in)	1 in
Minimum Bore (mm)	10 mm
Maximum Bore (mm)	25 mm
Hardened Teeth	Yes
Number of Hubs	1
Hub Projection (in)	1.094 in
Pitch Type	Single
Overall Width (in)	1.59375 in

General Specifications

UPC	662289225071
Weight	0.54 LB
Packaged Length	2.80 IN
Packaged Width	2.50 IN
Packaged Height	1.50 IN
HTC	8483.90.1050
Country of Origin	China
