• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Chain Pitch (in)	0.625 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Pitch Diameter (in)	4.59 in
Product Type	Finished Bore Roller Chain Sprocket
Material	Steel, Hardened Teeth
Number of Teeth	23
Outside Diameter (in)	4.922 in
Hub Projection (in)	0.662 in
Length Through Bore (in)	1 in
Tooth Width (in)	0.343 in
Bore Type	Finished Bore
Hub Type	Type B
Sprocket Material	Steel, Hardened Teeth
Hub Diameter (in)	3 in
Overall Length (in)	1 in
Number of Strands/Width	1
Bore Diameter (in)	1.1875 in
Keyway Size	1/4 X 1/8
Pitch Type	Single
Hardened Teeth	With Hardened Teeth
Maximum Bore (mm)	0 mm
Maximum Bore (in)	1.19 in
Minimum Bore (mm)	0 mm

General Specifications

UPC	662289984695
Weight	2.78 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.90.1050
Country of Origin	United States of America
