• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Chain Pitch (in)	0.625 in
Pitch Diameter (in)	2.415 in
Number of Teeth	12
Material	Steel, Hardened Teeth
Product Type	Finished Bore Roller Chain Sprocket
Outside Diameter (in)	2.708 in
Bore Type	Finished Bore
Number of Strands/Width	1
Bore Diameter (in)	0.75 in
Length Through Bore (in)	1.016 in
Hub Type	Type B
Tooth Width (in)	0.343 in
Hub Diameter (in)	2 in
Hub Projection (in)	0.656 in
Pitch Type	Single
Hardened Teeth	With Hardened Teeth
Keyway Size	3/16 X 3/32
Maximum Bore (in)	0.75 in
Maximum Bore (mm)	0 mm
Minimum Bore (mm)	0 mm

General Specifications

UPC	662289153589
Weight	0.82 LB
Packaged Length	3.06 IN
Packaged Width	3.06 IN
Packaged Height	1.31 IN
HTC	8483.90.1050
Country of Origin	United States of America
