• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	12
Material	Steel, Hardened Teeth
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Chain Pitch (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Pitch Diameter (in)	1.932 in
Max Bore (in)	1 in
Min Bore (in)	0.375 in
Bore Type	Bushed Bore
Outside Diameter (in)	2.166 in
Overall Length (in)	1.51225 in
Number of Strands/Width	1
Hub Diameter (in)	2.015 in
Maximum Bore (in)	1 in
Maximum Bore (mm)	25 mm
Minimum Bore (mm)	10 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289224616
Weight	0.40 LB
Packaged Length	2.90 IN
Packaged Width	2.80 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
