• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Pitch Diameter (in)	3.672 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Chain Pitch (in)	0.5 in
Product Type	Finished Bore Roller Chain Sprocket
Material	Steel, Hardened Teeth
Number of Teeth	23
Bore Type	Finished Bore
Outside Diameter (in)	3.938 in
Bore Diameter (in)	1 in
Number of Strands/Width	1
Hub Type	Type B
Tooth Width (in)	0.284 in
Hub Projection (in)	0.71875 in
Length Through Bore (in)	1 in
Hub Diameter (in)	3.016 in
Hardened Teeth	With Hardened Teeth
Keyway Size	1/4 x 1/8
Pitch Type	Single
Minimum Bore (mm)	0 mm
Maximum Bore (in)	1 in
Maximum Bore (mm)	0 mm

General Specifications

UPC	662289153350
Weight	1.94 LB
Packaged Length	4.56 IN
Packaged Width	4.56 IN
Packaged Height	1.56 IN
HTC	8483.90.1050
Country of Origin	United States of America
