• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Number of Teeth	12
Chain Pitch (in)	0.5 in
Material	Steel, Hardened Teeth
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Product Type	Finished Bore Roller Chain Sprocket
Pitch Diameter (in)	1.932 in
Bore Type	Finished Bore
Outside Diameter (in)	2.166 in
Bore Diameter (in)	0.625 in
Number of Strands/Width	1
Hub Type	Type B
Tooth Width (in)	0.284 in
Hub Diameter (in)	1.609 in
Length Through Bore (in)	0.891 in
Hub Projection (in)	0.596 in
Keyway Size	3/16 x 3/32
Pitch Type	Single
Hardened Teeth	With Hardened Teeth
Maximum Bore (in)	0.63 in
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm

General Specifications

UPC	662289162833
Weight	0.46 LB
Packaged Length	2.56 IN
Packaged Width	2.56 IN
Packaged Height	1.38 IN
HTC	8483.90.1050
Country of Origin	United States of America
