• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Material	Steel, Hardened Teeth
Product Type	Finished Bore Roller Chain Sprocket
Chain Pitch (in)	0.5 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Pitch Diameter (in)	1.775 in
Number of Teeth	11
Outside Diameter (in)	2.003 in
Bore Type	Finished Bore
Number of Strands/Width	1
Bore Diameter (in)	0.75 in
Length Through Bore (in)	0.891 in
Tooth Width (in)	0.284 in
Hub Type	Type B
Hub Projection (in)	0.596 in
Hub Diameter (in)	1.453 in
Hardened Teeth	With Hardened Teeth
Keyway Size	3/16 X 3/32
Pitch Type	Single
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm
Maximum Bore (in)	0.75 in

General Specifications

UPC	662289252824
Weight	0.34 LB
Packaged Length	2.56 IN
Packaged Width	2.56 IN
Packaged Height	1.38 IN
HTC	8483.90.1050
Country of Origin	United States of America
