• This Product has the Browning Exclusive Twice the Life Guarantee
• Finished bored sprockets are furnished with Standard Keyway on Centerline of Tooth and Hollow Head Setscrew over Keyway.

Technical Specifications

Material	Steel, Hardened Teeth
Chain Pitch (in)	0.375 in
Chain Used	No. 35, 3/8 in. Pitch ANSI Chain
Product Type	Finished Bore Roller Chain Sprocket
Pitch Diameter (in)	2.873 in
Number of Teeth	24
Length Through Bore (in)	0.875 in
Hub Projection (in)	0.703125 in
Tooth Width (in)	0.168 in
Bore Type	Finished Bore
Outside Diameter (in)	3.073 in
Hub Diameter (in)	2 in
Sprocket Material	Steel, Hardened Teeth
Hub Type	Type B
Overall Length (in)	0.875 in
Number of Strands/Width	1
Bore Diameter (in)	1 in
Pitch Type	Single
Keyway Size	1/4 x 1/8
Hardened Teeth	With Hardened Teeth
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm
Maximum Bore (in)	1 in

General Specifications

UPC	662289152773
Weight	0.78 LB
Packaged Length	3.90 IN
Packaged Width	3.70 IN
Packaged Height	1.60 IN
HTC	8483.90.1050
Country of Origin	United States of America
