• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	1.125 in
Material	Steel, Hardened Teeth
Chain Used	No. 160, 2 in. Pitch ANSI Chain
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	15
Pitch Diameter (in)	9.619 in
Chain Pitch (in)	2 in
Max Bore (in)	3.75 in
Bushing Used	Split Taper
Bore Type	Bushed Bore
Outside Diameter (in)	10.609 in
Overall Length (in)	3.140625 in
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289106912
Weight	22.80 LB
Packaged Length	10.61 IN
Packaged Width	10.61 IN
Packaged Height	3.16 IN
HTC	8483.90.1050
Country of Origin	China
