• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	1.125 in
Pitch Diameter (in)	8.988 in
Bushing Used	Split Taper
Max Bore (in)	3.75 in
Number of Teeth	14
Material	Steel, Hardened Teeth
Chain Used	No. 160, 2 in. Pitch ANSI Chain
Chain Pitch (in)	2 in
Product Type	Bushed Roller Chain Sprocket
Outside Diameter (in)	9.963 in
Overall Length (in)	3.140625 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289276899
Weight	19.90 LB
Packaged Length	9.96 IN
Packaged Width	9.96 IN
Packaged Height	3.16 IN
HTC	8483.90.1050
Country of Origin	China
