• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	11.968 in
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	25
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Min Bore (in)	1.125 in
Material	Steel, Hardened Teeth
Max Bore (in)	3.75 in
Chain Pitch (in)	1.5 in
Overall Length (in)	3.219375 in
Outside Diameter (in)	12.774 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Maximum Bore (mm)	95 mm
Minimum Bore (mm)	28 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289296682
Weight	29.23 LB
Packaged Length	14.40 IN
Packaged Width	13.70 IN
Packaged Height	2.90 IN
HTC	8483.90.1050
Country of Origin	China
