• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Min Bore (in)	1.125 in
Pitch Diameter (in)	11.492 in
Product Type	Bushed Roller Chain Sprocket
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Material	Steel, Hardened Teeth
Max Bore (in)	3.75 in
Number of Teeth	24
Chain Pitch (in)	1.5 in
Overall Length (in)	3.219375 in
Outside Diameter (in)	12.294 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Minimum Bore (mm)	28 mm
Maximum Bore (mm)	95 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289166657
Weight	27.30 LB
Packaged Length	14.00 IN
Packaged Width	13.70 IN
Packaged Height	2.50 IN
HTC	8483.90.1050
Country of Origin	China
